ENGINE/TANKER 84

 APPARATUS FEATURES

Manufacture Date:

Purchase Cost:

Motor: Cummins ISX15 550HP w/ VGT^TM Turbocharger

Transmission: Allison EVS4000 6-Speed Automatic

Suspension: Front - Leaf Spring (10) w/ Meritor MFS-23 Axle

                     Rear - Ridewell Dynalastic RD202 w/ Meritor RT-46-160 Axle

Tires: Front - 425/65R-22.5 20PR "L" G296 MSA

           Rear - 11R-22.5 16PR "H" G622 RSD

Fuel Capacity: 68 Gallons

Vehicle GVW: 67,620 Pounds

Pump: 1500 GPM Waterous CSUC20C Single-Stage

Tank: 3000 Gallon UPF PT3^TM Poly-Tank

Inverter/Charger: NewMar 'Perfect Wave' Series 12-3000IC-DV (3000W/6500W Surge 105A)

Special Features:

Tank Dumps X3 (Left/Right/Rear), Front/Rear Tank-to-Pump Valves, 12V Scene Lighting, Insta-Chain Automatic Snow Chains, Trident Air Primer (Automatic/Manual), Rear LDH Intake/Discharge, Monarch Intake Valves, Side/Rear View Camera's, 3000 Gallon Portable Fol-Da-Tank (FDTA-3000), FRC Max-Vision Tank Level Lights, TFT Crossfire Deluge Gun, Akron Mercury Monitor

Ladders: Zico LAS-XT Rack w/ (1) 24' Extension {2-section}, (1) 14' Roof, (1) 10' Folding Attic

Emergency Lighting: Whelen Emergency Lighting

TAKE A LOOK INSIDE

 Driver Side Front

(1) Traffic Safety Vest, (1) Driver's Coat, (1) portable radio,

(under-seat compartment) 12oz cups, toilet paper and work gloves

Driver Side Crew Cab

(2) Traffic Safety Vests, (2) ‘Scott NXG’ SCBA

Crew Cab Area

   Crew Passenger Side: (1) 4' Drywall Hook, (1) Irons Set (Flathead Axe/Halligan Bar), Elevator Keys

Overhead: Spare Scott SCBA Facepieces

EMS Compartment: (1) Aid Bag, (1) AED, Bag of Emergency Blankets,

 Crew Driver Side: Cooler for water bottles

 Driver Side Front Compartment (D1)

(Pass-Thru to Passenger Side)

Spare DEF Container, Apparatus Cleaning Supplies

Driver Side Pump Panel

(1) 6' New York Hook, (1) 1 3/4" x 200' Preconnect Attack Line w/ Akron Assault Nozzle (yellow),

(1) 2" x 250 Preconnect Heavy Attack Line w/ Akron Assault Nozzle (green),

Belly Tray: (1) 4" storz x 25' LDH Short Shot (blue), (1) 4 1/2" NST - 5" storz x 25' Hydrant Sleeve (white)

Driver Side Dunnage

(1) 5 Gallon Class "A" Foam

Long Tool Storage (Best access from passenger side)

Driver Side Mid Compartment (D2)

TOP SHELF AND WALL

(1) Rachet Hydrant Wrench, (1) Mallet, (1) Foam Wrench, (4) LDH Wrenches, (2) Spanner Wrenches,

(1) Hydrant Wrench, (1) 2 1/2" Fog Nozzle Tip, (1) 2 1/2" Smooth Bore Nozzle, (1) 4 ½” female x 4” storz,

(1) 6” female x 5” female, (1) 6” male x 5” female, (1) 6" double female, Bag of Earplugs,

Friction Loss and Tanker Ops Cheat Sheets, Dust Masks, (1) Leather Hose Jacket,

(4) Rope Hose Tools, (1) 1 1/2" Smooth Bore Nozzle, Assortment of Spare Gaskets,

WD40, Caution Tape, Duct Tape

SLIDE-OUT SHELF

Front: (2) 1 1/2" double female, (2) 1 1/2" double male, (1) 1 1/2" x 3/4" reducer, (1) 1 1/2" cap,

(2) 2 1/2" double female, (2) 2 1/2" double male, (1) 2 1/2" x 1 1/2" reducer, (1) 2 1/2" cap,

(1) 2 1/2" 3pc Stack Tip, (1) Deluge Fog Nozzle, (1) 2 1/2" x [2] 2 1/2" Gated Wye,

(1) 4" storz x [2] 2 1/2" Gated Wye, (1) 4 1/2" x 4" Storz Hydrant Valve,

Foam Nozzle Aerator, Foam Eductor, (1) Garden Hose Adapter

Back: (2) 4" x 5" storz reducers, (2) 4" storz x 2 1/2" female, (1) 4" storz x 2 1/2" male, 4" storz cap,

Tool Box, Socket Kit

BOTTOM WALL

25' Air Hose, 15' Garden Hose, Misting Nozzle (rehab)

The space located on the back side of the bottom wall is reserved for the Drivers turn-out gear.

Driver Front High Side Compartment (D3)

Front: (1) 4' Drywall Hook, (1) Pickhead Axe, (1) Halligan Bar, (1) 3' Drywall Hook

Back: (1) Crowbar, (1) Large Bolt Cutter, (1) Prybar, (1) 8lb Sledge Hammer, (1) "K-Tool"

Driver Side Wheel-Well Compartment (Front)

(1) ‘Scott NXG’ SCBA (Driver's SCBA)

 Driver Rear High Side Compartment (D4)

(1) Foam "Pro/Pak", Forestry Hose Pack (100' Forestry Line w/Nozzle), Haz-Mat Spill Kit, Clay Absorbent

Driver Side Rear Compartment (D5)

TOP SHELF

(4) 28" Collapsible Traffic Cones, E-Flare Kit, Flare Kit, DOT Kit,

(6) PFD [green duffle bags], 75' Rope Throwbag

BOTTOM SHELF

(1) 24” Blowhard PPV Fan, (1) LDH 3-Way Manifold 4" storz x 4" storz/[2] 2 1/2" NST,

(1) 4" storz x 25' LDH Short Shot (blue), (1) 4" storz x 50' LDH Short Shot (red)

Passenger Side Front

(1) Traffic Safety Vest, (1) ‘Scott NXG‘ SCBA, Scott 'Protege' multi-gas meter,

various ‘Box Area’/ 'ADC' maps, various miscellaneous forms, Toughbook Computer,

NAERG Haz-Mat Book, (1) “Crew Personal Accountability Tag” ring collector

Passenger Side Crew Cab

(2) Traffic Safety Vests, (2) ‘Scott NXG’ SCBA, (4) ‘Survivor’ flashlights (overhead)

Passenger Side Front Compartment (P1)

(Pass-thru to Drivers Side)

(1) "Big Easy" Lock-Out Tool Kit, Remote Cab-Lift Control

Passenger Side Pump Panel

(1) 6' New York Hook, (4) Storz Wrenches, (2) Spanner Wrenches, (1) Hydrant Wrench,

(1) 1 3/4" x 200' Preconnect Attack Line w/ Akron Assault Nozzle (blue)

BELLY TRAY: (1) 1 3/4" x 100' Preconnect Auto/Trash Line w/ Akron Assault Nozzle (orange)

Passenger Side Dunnage

(2) 5 Gallon AFFF Class "B" Foam, (2) Brush Rakes, (2) Pitch Forks,

(2) Flat Shovels, (2) Dirt Shovels, (2) Street Brooms

Passenger Side Mid Compartment (P2)

TOP SHELF

(2) Portable Streamlights, (2) Wood Wheel Chocks, (1) Electrical Pigtail Kit

BOTTOM SHELF

(1) Class 'A' Water Fire Extinguisher, (1) Class 'ABC' Fire Extinguisher, (1) Class 'BC Fire Extinguisher

(1) Class 'D' Fire Extinguisher, (1) 4" storz x 50' LDH Short Shot (red), (1) 4" storz x 25' LDH Short Shot (blue),

(2) 3" x 25' Short Shots, (2) 1 3/4" x 50' Spares, (1) Mallet

Passenger Front High Side Compartment (P3)

(1) high-rise pack - includes the following equipment/tools:

(150’ x 1 ¾” w/ 'SaberJet' nozzle, 2 ½” x 1 ½” gated wye, spanner wrench, adjustable wrench)

Passenger Rear High Side Compartment (P4)

(1) Rapid Intervention Team Bag, (1) Search/Tag-Line Rope Kit

Passenger Side

Wheel-Well Compartments

(6) Spare Scott SCBA Cylinders

Passenger Side Rear Compartment (P5)

TOP SHELF

(2) Salvage Covers, (1) Salvage Kit, (1) Chimney Kit, (1) Bucket/Shovel, (1) Flame Retardant Cover,

(1) 100' Utility Rope, (1) Ladder Belt Kit, (1) Lock-Out/Tag-Out Kit, (1) Sprinkler Kit

BOTTOM SHELF

(1) 6" Floating Strainer. (1) 6" Low-Lift Strainer, (1) 6" Barrel Strainer, (1) 6" Jet Siphon,

(1) LDH Master Steam Monitor Base, (1) Portable Tank Hose Clamp

                 RD1                                                                                                                           RP1

Rear

Hose Bed, Upper and Lower Back-Steps

1200’ x 4” LDH supply line, (1) 250’ x 2 1/2" Preconnect Blitz Line w/ 2 1/2" 'Akron' Assault nozzle,

(2) 300' x 3" FDC Lines, (1) 300' x 3" Preconnect Heavy Blitz Line w/Mercury Monitor (500GPM),

(1) Humat Valve w/hydrant wrench and 2 1/2” Hydrant Valve, (1) 4” x [2] 4” Siamese,

(4) Storz Wrenches, (2) Spanner Wrenches, (1) Hydrant Wrench

Compartments RD1 and RP1

Each side has: (1) 6" x 15' Hard Sleeve, (1) 10' Trash/Arson Hook

Hose Bed

(view from 'top dunage')

Top Dunage (TD1)

Click on: "Driver Side Dunnage" and/or "Passenger Side Dunnage" for list of equipment
